Vacuum Truck

Price : Contact us

Products added to cart

Short description:

Vacuum Truck by Hiephoa Group is designed to serve environment. There are several types of...

Vacuum Truck by Hiephoa Group is designed to serve environment. There are several types of vacuum truck for customers to choose

Specifications

MODEL

FG8JJSB/HIEPHOA-HP

630305-220/HIEPHOA-HB

WU342L-NKMTJD3/HIEPHOA-HP1

630305-220/HIEPHOA-HP

630305-220/HIEPHOA-HP

CHASSIS

HINO FG

MAZ 630305-220

HINO WU

MAZ 630305-220

MAZ 630305-220

Total mass

15.100

22.550 kg

7.890 kg

22.810 kg

23.250 kg

Payload

7.370 kg

9.130 kg

3.300 kg

10.100 kg

10.250 kg

Overall dimensions (LxWxH)

7.200 x 2.450 x 3.100 mm

8.800 x 2.500 x 3.260 mm

5.740 x 1.960 x 2.700 mm

8.650 x 2.500 x 3.310 mm

8.810 x 2.500 x 3.310 mm

Engine system

Diesel, 4 cycles, 6 straight turbocharges cylinders

Diesel, 4 cycles, 8 straight V cylinders)

Diesel, 4 cycles, 4 straight turbocharges cylinders)

Diesel, 4 cycles, 8 straight turbocharges V cylinders)

Diesel, 4 cycles, 8 turbocharges V cylinders)

Max. output/rpm

167 kW/2.500 rpm

243 kW/2.100 rpm

92 kw/2.700 rpm

243 kW/2.100 rpm

243 kW/2.100 rpm

Wheel formula

4x2

6x4

4x2

6x4

6x4

Tank dimensions (LxWxH)

4.460 x 1.452 x  1.452 mm

4.500 x 1.612 x 1.612 mm

3.020 x 1.312 x 1.312 mm

4.945 x 1.612 x 1.612 mm

4.945 x 1.612 x 1.612 mm

Tank capacity

 6700

 8300

3000

Vacuum pump

9150

Vacuum pump

Sludge/Dump: 7500

Water: 2000

Vacuum pump & high pressure water pump

Note

- Please contact the supplier to receive more information and specifications

- Customization is available
